Temp Test UB500T 4KHZ IPR 6 Zones Archway Detector Gate

SHENZHEN UNISEC TECHNOLOGY CO.,LTD
Contact Now

Temp Test UB500T 4KHZ IPR 6 Zones Archway Detector Gate

Brand Name : UNIQSCAN

Model Number : UB500T

Certification : CE ISO

Place of Origin : SHENZHEN,CHINA

MOQ : 1 UNIT

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000set/day

Delivery Time : 5-8 working days

Packaging Details : Carton Box,2280*570*210mm *1ctn for Door Panel; 770*400*280mm *1ctn for Control Unit

Detecting zone : 6 zones

Sensitivity : 0-99 adjustable

Power Supply : AC85V-264V

Working temperature : -20ºC--+50ºC

Working Frequency : 4KHZ-8KHZ

Warranty : 2 years

Gross weight : 70KG

Accuracy : ± 0.5℃

Test distance : 5-15cm

Fast temperature detection speed : Non-contact,within one second

Contact Now

High Accuracy Archway Metal Detector Gate Price With Temperature Measuring Security Equipment System Solution

We owns all of the intellectual prope rights (IPR) to its core technologies ,and have a experience engineer team with senior x-ray detection exports, signal and imagine processing specialist . Our excellent technical developing capacity to support us are ability to have continuesly new production lines.

Key Feature:

  • 8/16/24 zones (option)
  • 4 hours backup battery (option)
  • 0-255 sensitivity
  • 90 pcs for 20" container

Parameters:

Detector zone : 8/16/24Zones (Option)
Sensitivity : 0 to 255 sensitivity
Display way: 7.0 inch LCD screen
Sound & LED alarm: Both Side LED indicator ,easily show where the metal is
Power supply: AC85V-264V
Working Frequency: 4KHZ-8KHZ
Operation Temperature: -20ºC--+50ºC
Warranty: 2 years
Certification: CE, ISO


Characteristic & Function:

  • Six mutual over-lapping detecting zones, Simultaneous alarm from multi- zones;
  • Sensitivity adjustable: Each zone has 256 sensitivity level, 0-255 adjustable
  • 7.0 inch LCD screen
  • Infrared remote control
  • Sound & LED alarm: Both Side LED indicator ,easily show where the metal is.
  • Automatically count passengers and alarm times
  • Alarm strength indicator on control panel
  • Password protection, only the authorized person can operate.
  • Easy assembly: designed with only 2 pieces cables and 8 screws, simply-to-follow instruction.
  • Harmless to human body: is harmless with heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.
  • Using high density fireproof material
  • Program Self-diagnostic when power on, no need initial or periodic calibration
  • Modularization design, easy for maintenance and replacement.
  • Sensitivity Test piece: One yuan Coin, omnidirectional detection
  • 4-8 hours backup battery (Option)

Examining Standard:

  • Electrical Equipments standardized by EN60950.
  • Radiation standardized by EN50081-1.
  • Anti-inference standardized by EB50082.
  • Execute the standard of National Standard of Metal Detector

Applications:

  • Airports
  • Correctional Facilities
  • Public Buildings
  • Private Buildings
  • Schools
  • Special Events
  • Loss Prevention
  • Nuclear Facilities
  • Transportation Terminals
  • Courthouses
  • Corporate Security
  • Historical Landmarks

Temp Test UB500T 4KHZ IPR 6 Zones Archway Detector Gate

Temp Test UB500T 4KHZ IPR 6 Zones Archway Detector Gate
Temp Test UB500T 4KHZ IPR 6 Zones Archway Detector Gate
A:5 Digital LED Count:Easy show&count passengers.
B:8 Screws:Easy assembly and install.
C:Socket:Easy connect both door panels.
D.Power Line:Support UK/European/USA standard.
E.Integrated Circuit Board:Intelligent circuit.
F.Long range Sensor:Accuracy check.
G.Tamper Indication:Easy distinguish interference.
H.Foot Cover:Easy fastness.

Detail Photo :

Temp Test UB500T 4KHZ IPR 6 Zones Archway Detector Gate

Temp Test UB500T 4KHZ IPR 6 Zones Archway Detector Gate

Shenzhen Unisec Technology Co., Ltd is a professional security scanner equipment manufacturer, specialized the development and research in the x-ray imagine tehnology, metal detection technology, explosive detection, liquid detection and relative security services.

OUR BRIEF

We always adhere to customer-centric, the principles of honesty and trustworthiness, is committed to efforts to improve and continuous innovate its own responsibility .

OUR TECHNOLOGY
We owns all of the intellectual property rights (IPR) to its core technologies ,and have a experience engineer team with senior x-ray detection exports, signal and imagine processing specialist , excellent technical support and maintance engineers.

OUR SERVICES
We strictly in accordance with the ISO9001 quality standard requirements from production research , manufacture, marketing to after services, established a complete quality management and assurance system . Also we take effective marketing management protection measures to control the products qulity ,working efficiency and service attitudes ,to ensure all our clients have our best quality products and best services.

Temp Test UB500T 4KHZ IPR 6 Zones Archway Detector Gate
